45 skeleton

POWER
1200HP / 882kW

LENGTH OVERALL
13.79M / 45.24FT

BEAM
3.92M / 12.86FT

---

DESIGN

---

NAVAL ARCHITECTURE

---

LENGTH OVERALL

---

BEAM

---

DRAUGHT

---

CONSTRUCTION

---

HULL SHAPE

---

ENGINES

---

PROPULSION

---

MAXIMUM SPEED

---

FUEL TANK

---

WATER TANK

---

BLACK WATER TANK

---

MAXIMUM LOAD

---

MAX PASSENGERS

---

CLASSIFICATION

---

* preliminary performance data

---

RIBBON YACHTS / EVDM DESIGN

---

RIBBON YACHTS

---

13.79M / 45.24FT

---

3.92M / 12.86FT

---

0.73M / 2.39FT

---

PRE-PREG CARBON FIBRE

---

DEEP V-PLANNING DEADRISE 18 DEGREES

---

3x Mercury 5.7L V10 400HP / 294kW

---

3x 5.44” Offshore HD Gearcase

---

40+ KNOTS *

---

1600 LITRES / 423 GALLONS

---

320 LITRES / 84 GALLONS

---

100 LITRES / 26 GALLONS

---

1.250KG

---

14

---

CE APPROVED B CATEGORY

---
